Transform Your Air Compression System with
Oil-Free Scroll Compressors on Tank
- 100% Oil-Free Air
- Quiet Operation
- Compact- Easy to Service
Professional and Reliable Compressed Air Solutions
Functionality of an Oil-Free Scroll Air Compressor
An oil-free scroll compressor is a sophisticated air compression solution that employs two spiral-shaped scroll elements to efficiently compress air without relying on oil lubrication. Below are the primary features and advantages of oil-free scroll compressors:
| Model | Max Working Pressure (PSI) | Free Air Delivery of Unit at working Pressure (CFM) | Voltages Available | Motor (HP) | Noise Level (dBA) | Air Outlet Discharge Size | Tank (Gallon) | Length (in) | Width (in) | Height (in) | Weight (lbs) |
|---|---|---|---|---|---|---|---|---|---|---|---|
| SOT 5/D | 150 | 14 |
220V 60HZ 3PhZ 480V 60HZ 3PhZ 600V 60HZ 3PhZ |
5 | 58 | G1/2 | 80 | 30 | 24 | 63 | 352 |
| SOT 7/D | 150 | 22 | 7.5 | 59 | G1/2 | 80 | 32 | 24 | 65 | 396 | |
| SOT 10/D | 150 | 29 | 10 | 63 | G3/4 | 80 | 32 | 24 | 65 | 450 |
Operating Principle
- Incorporates two scrolling mechanisms: one stationary and one rotating
- The rotating scroll operates in a circular trajectory within the stationary scroll
- Air is enclosed between the scrolls, compressing as it progresses toward the center
- Provides 100% oil-free air, officially certified to ISO 8573-1 Class 0 standards
Advantages
- Clean, contamination-free air: Eliminates the risk of oil contamination
- Low maintenance: No need for oil changes or filter replacements
- Energy efficient: Generates only the necessary amount of air
- Compact design: Small footprint, ideal for space-constrained environments
- Quiet operation: Achieves noise levels as low as 48 dBA
- Reliable performance: Fewer moving parts enhance operational reliability. Oil-free scroll compressors are particularly well-suited for applications demanding pure, contaminant-free air, such as medical facilities, laboratories, food and beverage production, and electronics manufacturing.
Key Characteristics
- Oil-free design: Engineered without the use of oil in the compression chamber
- Self-lubricating materials: Incorporates materials such as Teflon as a replacement for oil
- Minimal moving parts: Comprises only two primary components (fixed and orbiting scrolls)
- Consistent airflow: Delivers a reliable stream of compressed air
- Reduced noise and vibration: Operates more quietly compared to other compressor types
Applications and Industries
Oil-free scroll compressors are well-suited for:
- Medical and laboratory settings
- Pharmaceutical manufacturing
- Food and beverage production
- Electronics fabrication
- Automotive coating
- Research and development facilities
- Dental applications
WHY SCROLL COMPRESSOR
Quiet Operation
Scroll compression drastically reduces noise.
Perfect for indoor use where people are working nearby.
100% Oil-Free Design
Produces clean, oil-free air ideal for medical, food, and precision manufacturing use.
Long-Term Warranty
Backed by a 6,000-hour or 5-year warranty — guaranteed performance and peace of mind.
Maintenance-Free Reliability
No lubrication or piston wear. Fewer moving parts mean longer life and lower costs.
No In-rush Current
Thanks to built in frequency inverter. Start stop as much as needed with no in- rush current. Ideal to use where power supply is limited.
Compact Integrated System
Space-saving design unites all components in one efficient vertical package.
Modular Desiccant, Refrigerant Air Dryers, Air Tanks, Inline Filters, Auto Drains, Water Oil Separators…
Ready to Dive Into the World of Air Power?
Rest assured, you’re in great hands with a company dedicated to creating smart, efficient compressors that work as hard as you do, all backed by a reliable lifetime warranty.
